Why We Chose Arduino Over Raspberry Pi for Our Smart Vending Machine

Last quarter, a client came to us with a problem. They ran a chain of 40 vending machines across three cities in the UK. Each machine was a standalone unit — no connectivity, no remote monitoring, no way to know when a row was empty until a customer complained.

They wanted to retrofit them with smart capabilities: real-time inventory tracking, remote pricing updates, and payment integration. The obvious debate started immediately in our engineering room — Arduino or Raspberry Pi?

We went with Arduino. Here’s exactly why, and what we learned.

The Architecture Decision That Mattered Most

The client’s requirement was straightforward: each machine needed to read 12 motor position sensors, control 12 dispensing motors, accept contactless payments via NFC, and send data over WiFi to a cloud dashboard. All on a 12V DC supply with no active cooling.

On paper, a Raspberry Pi Zero 2 W can do all of that. It runs Linux, has WiFi built in, and costs around £15. But when we mapped out the real power constraints and reliability needs, the decision flipped.

Power Consumption Isn't a Detail — It's the Requirement

A Raspberry Pi Zero 2 W idles at around 0.8W and can spike to 2.5W under load. That doesn't sound like much until you multiply it by 40 machines running 24/7. More importantly, Pi boards require a clean 5V supply. In a vending machine, the main power comes from a 12V battery-backed system that also drives motors and compressors. Voltage dips during motor starts are common.

We tested three units in our lab. When a motor kicked in, the Pi would brown out and reboot. We added a dedicated 5V regulator with a 470µF capacitor bank — it helped, but not enough for reliable field operation.

Our team switched to an nRF52840-based Arduino-compatible board. It runs on 1.7V to 3.6V directly, draws 1.5mA in active mode (0.01W), and handles the motor noise without a hiccup. No brownouts, no reboots, no extra power circuitry.

Real-Time Control vs. Linux Overhead

A Raspberry Pi runs a full operating system. That means boot time of 30–40 seconds, background processes, SD card wear, and the occasional filesystem corruption from an unexpected power loss. In a vending machine that might get its power cycled during cleaning or maintenance, that's not acceptable.

Our firmware engineers wrote the entire control loop in Zephyr RTOS on the nRF52. Boot time: 200 milliseconds. The machine reads sensors, checks payment status, and dispenses a product within 500ms of a user tapping their card. No OS overhead, no SD card to corrupt, no boot delays.

We had one prototype Pi unit that corrupted its SD card three times during our two-month field trial. We replaced it with an Arduino-based board and haven't touched it since.

What About Connectivity?

This is where people usually argue for Pi. "But it has built-in WiFi and runs Node-RED or MQTT easily." True. But our Arduino board uses an ESP32 coprocessor for WiFi, communicating over SPI to the main nRF52. The ESP32 handles MQTT over TLS to AWS IoT Core. Total BOM cost for the two-chip solution: about £8.

The separation matters. The ESP32 can crash, lose connection, or need a firmware update — the nRF52 keeps the vending machine running locally. The user still gets their drink. Inventory data queues locally and syncs when connectivity returns. With a Pi, if the OS freezes, the whole machine stops.

Development Speed and Remote Debugging

We do a lot of prototyping in-house. For this project, we had three engineers working in parallel: one on the PCB layout in KiCad, one on the Zephyr firmware, and one on the cloud dashboard. We shipped the first working prototype to the client in 14 days.

Here's why Arduino won on development speed: we could flash firmware over BLE from a phone. No need to SSH into a Pi, no network configuration, no SD card swapping. Our field technician could update firmware on 40 machines in one afternoon, standing next to each unit with a tablet.

The client later asked us to add a feature — remote temperature monitoring for refrigerated rows. We added a DS18B20 sensor to the I2C bus, wrote 40 lines of code, and pushed the update over BLE. Total engineering time: 4 hours.

When Would We Have Used Pi?

Honestly? If the client needed a full touchscreen UI with rich graphics, or if they wanted to run computer vision for product recognition, we'd have gone Pi. We've built those systems before — one of our earlier projects used a Raspberry Pi 4 with a camera module to detect empty slots. But that was a different use case with different power and reliability requirements.

For this vending machine project, Arduino was the right call. Lower power, higher reliability, faster development, easier field updates. Need a Customizable Vending Machine? We build custom hardware, firmware, and complete vending solutions.

What This Means for Your Project

If you're building a connected product that needs to run reliably for years without maintenance, think carefully about the Linux vs. RTOS tradeoff. Raspberry Pis are fantastic prototyping tools. We use them in our lab all the time. But for production hardware that ships to customers, we almost always end up with a microcontroller-based design.

We've done this for vending machines, industrial sensors, smart locks, and medical devices. If you need a team that knows when to use Arduino and when to reach for something else, that's what we do. We've got engineers who've shipped boards running nRF52, ESP32, STM32, and even custom Silabs designs for Matter-compatible devices.

Need to Hire Remote Arduino Developers for your next hardware project? We build the firmware, design the PCBs in KiCad, handle 3D-printed enclosures, and ship fully tested prototypes. No fluff, no buzzwords — just working hardware that stays working.
